Monel >> Monel 400, Monel K-500, Monel R405
Inconel >> Inconel 600, Inconel 601, Inconel 625, Inconel 617, Inconel 690, Inconel 718,
Inconel X-750, Inconel 926
inconel 718 forged bar, Inconel 718 round bar Price ,Astm B637,Astm B637 Forged Round Bar Inconel 718 price
Incoloy >> Incoloy A-286, Incoloy 800, Incoloy 800H, Incoloy 800HT, Incoloy 825, Incoloy 926, Nimonic 75, Nimonic 80A, Nimonic 263, Nimonic 90, Incoloy 901, Incoloy 925
inconel 718 forged bar, Inconel 718 round bar Price ,Astm B637,Astm B637 Forged Round Bar Inconel 718 price
Hastelloy >> Hastelloy C-276, Hastelloy C-22, Hastelloy C-4, Hastelloy B-2, Hastelloy B-3,
Hastelloy X, Hastelloy G, Hastelloy G2, Hastelloy G3, Hastelloy G30
inconel 718 forged bar, Inconel 718 round bar Price ,Astm B637,Astm B637 Forged Round Bar Inconel 718 price
Austenitic stainless steel >> 904L, Nitronic 60, XM-19, Nitronic 40, 316Ti, 316N, 316LN, 317,
317L, 310S, 253MA
inconel 718 forged bar, Inconel 718 round bar Price ,Astm B637,Astm B637 Forged Round Bar Inconel 718 price
DP Steel >> 254SMO, F50, 2205, F53, F55 (ZEROM 100) , F60, F61, F65
inconel 718 forged bar, Inconel 718 round bar Price ,Astm B637,Astm B637 Forged Round Bar Inconel 718 price
PH Steel >> 15-5PH, 17-4PH, 17-7PH
|
Designation |
Nearest Related Specification |
Description |
|
ALLOY C-276 |
ASTM B-574, 575, 619, 622, 626 |
Outstanding resistance to a variety of environments, including strong oxidisers, hot contaminated mineral acids, wet or dry chlorine contaminated media, acetic anhydride and sodium chloride solutions. |
|
NICKEL 200 |
ASTM B160-3, BS3072: NA11 |
Commercial wrought nickel; good mech. props; excel.resistance to many corrosion environments including foods, synthetic fibres and alkalis. |
|
MONEL* |
ASTM B127, 163-165, BS3072-6: NA13 |
Good resistance to corrosion by sea water, dilute sulphuric, chemical, steam and petroleum plant, marine and pickling equipment. |
|
MONEL* |
BS3072-6: NA18 QQ-N-286D |
Similar corrosion resistance to Monel Alloy 400, but amenable to precipitation-hardening to give high strength. For propeller and pump shafts, bolts, doctor blades and valves. |
|
INCONEL* |
ASTM-B163, 166, 168, BS 3072-6: NA14 |
Combines excellent high temp strength with resistance to oxidising, carburising, nitriding and reducing atmospheres. |
|
INCONEL* |
|
Improved alloy where maximum high temp strength and oxidation resistance required. Good sulphidation and carburising resistance. |
|
INCONEL* |
ASTM B443,444,446 |
For wet corrosive, high temp and cyrogenic service. High resistance to range of corrosive solutions including acids, salts and sea water where pitting, crevice or stress cracking may occur. Excellent for overlay and dissimilar metal welds. |
|
INCOLOY* |
BS 3072-6: NA17 |
A general purpose heat-resisting alloy with particular resistance to carburisation and alternating carburisation and oxidation. For furnace parts, heat-treatment and vitreous enamelling equipment. |
|
INCOLOY* |
ASTM B163, 407-9, BS 3072-16: NA15 |
Resistant to chloride-ion stress-corrosion cracking, excellent high temperature strength and immunity to Sigma phase formation. Widely used for petrochemical and high temperature process equipment. |
|
INCOLOY* |
ASTM BI63, B423-5, BS 3072-6: NA16 |
Developed for use in aggressive corrosive environments. Exceptional resistance to corrosion by acids and alkalis in reducing or oxidising conditions. It is resistant to stress corrosion cracking and pitting and used for chemical plant and pickling plant. |
|
DUPLEX STAINLESS |
ASTM A240, A47 9, A959 |
2507 is a duplex stainless steel with very high strength. It has very high resistance to uniform corrosion, pitting and crevice corrosion and to stress corrosion cracking. |
|
AUSTENITIC STAINLESS STEEL 310 (S31000) |
ASTM A240 |
A heat resistant austenitic stainless steel with better scaling resistance than standard grades. Usable to 1035°C in intermittent service, 1150°C in continuous service |
|
AUSTENITIC STAINLESS STEEL 253MA (S30815) |
ASTM A240 |
253 MA is microalloyed with rare earth metals (REM) for excellent heat resistance. Best used at 850-1100°C. Can become brittle at room temperature after service at 600-850°C. |
|
AUSTENITIC STAINLESS STEEL 254SMO (S31254) |
ASTM A240 |
Highly corrosion resistant austenitic stainless steel containing 6% molybdenum, plus copper. Pitting resistance equivalent =43. |
|
ALLOY 31 |
ASTM B625, B462, B649, B366, B626 |
An advanced super-austenitic, high-chromium 6% moybdenum corrosion resisting alloy. Bridges the cost/performance gap between Ni-Cr-Mo alloys and 300 series stainless steels. Is used in the chemical process and petrochemical industries. |
|
Nominal Pipe Size |
Outside diameter |
Wall thickness |
|||||
|
SCH 5S |
SCH 10S |
SCH STD (40S) |
SCH XS |
SCH 160S |
SCH XXS |
||
|
1/8" |
10.29 |
- |
1.24 |
1.73 |
2.41 |
- |
- |
|
1/4" |
13.72 |
- |
1.65 |
2.24 |
3.02 |
- |
- |
|
3/8" |
17.15 |
- |
1.65 |
2.31 |
3.20 |
- |
- |
|
1/2" |
21.34 |
1.65 |
2.11 |
2.77 |
3.73 |
4.75 |
7.47 |
|
3/4" |
26.67 |
1.65 |
2.11 |
2.87 |
3.91 |
5.54 |
7.82 |
|
1" |
33.40 |
1.65 |
2.77 |
3.38 |
4.55 |
6.35 |
9.09 |
|
1 1/4" |
42.16 |
1.65 |
2.77 |
3.56 |
4.85 |
6.35 |
9.70 |
|
1 1/2" |
48.26 |
1.65 |
2.77 |
3.68 |
5.08 |
7.14 |
10.16 |
|
2" |
60.33 |
1.65 |
2.77 |
3.91 |
5.54 |
8.71 |
11.07 |
|
2 1/2" |
73.03 |
2.11 |
3.05 |
5.16 |
7.01 |
9.53 |
14.02 |
|
3" |
88.90 |
2.11 |
3.05 |
5.49 |
7.62 |
11.13 |
15.24 |
|
3 1/2" |
101.60 |
2.11 |
3.05 |
5.74 |
8.08 |
- |
16.15 |
|
4" |
114.30 |
2.11 |
3.05 |
6.02 |
8.56 |
13.49 |
17.12 |
|
5" |
141.30 |
2.77 |
3.40 |
6.55 |
9.53 |
15.88 |
19.05 |
|
6" |
168.28 |
2.77 |
3.40 |
7.11 |
10.97 |
18.24 |
21.95 |
|
8" |
219.08 |
2.77 |
3.76 |
8.18 |
12.70 |
23.01 |
22.23 |
|
10" |
273.05 |
3.40 |
4.19 |
9.27 |
12.70 |
28.58 |
25.40 |
|
12" |
323.85 |
3.96 |
4.57 |
9.53 |
12.70 |
33.32 |
25.40 |
|
14" |
355.6 |
3.96 |
4.78 |
9.53 |
12.70 |
35.71 |
- |
|
16" |
406.4 |
4.19 |
4.78 |
9.53 |
12.70 |
40.46 |
- |
|
18" |
457.2 |
4.19 |
4.78 |
9.53 |
12.70 |
45.24 |
- |
|
20" |
508.0 |
4.78 |
5.54 |
9.53 |
12.70 |
49.99 |
- |
|
22" |
558.8 |
4.78 |
5.54 |
9.53 |
12.70 |
53.97 |
- |
|
24" |
609.6 |
5.54 |
6.35 |
9.53 |
12.70 |
59.51 |
- |
Note:The dimensions are in millimeters
|
Standard |
– ASTM A270,ASTM A249,ASTM A511,ASTM A778 ,ASTM A312,ASTM A358,ASTM A409,ASTM A213,ASTM A790,ASTM A268,ASTM A269,ASTM A554,ASTM B338,ASTM B673,ASTM B674,ASTM B677,ASTM B675, ASTM B676, ASTM B690,ASTM A928,ASME B36.19,ASME B36.10– EN10216-5,EN10217-7,DIN 17456,DIN 17458 |
|
Size Range |
OD: NPS 1/8 -80, BN 6 – 2000, 10.3 – 2030 , Alao capilaryWT: Sch5s-Sch160s, SchXXH, STD,XS,XXSLength: Customization |
|
Grade |
S32750, 00Cr25Ni7Mo4N, 022Cr25Ni7Mo4N, 1.441, 1.4307/1.4301/304L/3, S30408/S30403, 0Cr18Ni9DQ, 1.4948/304H, 07Cr19Ni10, S30409, 1.4948, 06Cr23Ni13, S30908, SUS309S, SUS310S, 1.4845, S31008, S31008S, 06Cr25Ni20, 0Cr25Ni20, 1.4401/1.4404/316/31, S31635, SUS316Ti, 1.4571, 1.4571/316Ti, S31703, 022Cr19Ni13Mo3, 00Cr17Ni12Mo2, S31703, SUS317L, 1.4438, S41008, SUS410S, 1.4, 06Cr13, S11306, 0Cr13, S42000, SUS420J1, 1.4021, SUS420J2, 1.4028, S43020, 430F, SUS430F, 1.4104, , 301, 302, 303, 305, 309, 310, 316, 317, 321, 347, 403, 405, 416, 431, 444, 2205, 2507, 304/304L, 304DQ, 304H, 309S, 310S, 316/316L, 316Ti, 317L, 410S, 420J1, 420J2, 430F, 254Smo, 1.4529, HC276, 800, 825, 600, 601, 718, 750, 400, 630, XM19, C4, S30815, S31254, 174PH, F51, F60, F53, S32760, 253MA, HC2000, 800H, 926, GH2132, GH4169, GH3030, GH3039, GH4151, N04400, HB3, 0Cr13Ni5Mo, N08367, N08810 |
ASTM B111 / ASME SB111
Standard Specification for Copper and Copper-Alloy Seamless Condenser Tubes and Ferrule Stock
ASTM B161 / ASME SB161
Standard Specification for Nickel Seamless Pipe and Tube
ASTM B163 / ASME SB163
Standard Specification for Seamless Nickel and Nickel Alloy Condenser and Heat-Exchanger Tubes
ASTM B165 / ASME SB165
Standard Specification for Nickel-Copper Alloy (UNS N04400)* Seamless Pipe and Tube
ASTM B167 / ASME SB167
Standard Specification for Nickel-Chromium-Iron Alloys, Nickel-Chromium-Cobalt-Molybdenum Alloy (UNS N06617),and Nickel-Iron-Chromium-Tungsten Alloy (UNS N06674) Seamless Pipe and Tube
ASTM B395 / ASME SB395
Standard Specification for U-Bend Seamless Copper and Copper Alloy Heat Exchanger and Condenser Tubes
ASTM B407
Standard Specification for Nickel-Iron-Chromium Alloy Seamless Pipe and Tube
ASTM B423 / ASME SB423
Standard Specification for Nickel-Chromium-Molybdenum-Columbium Alloys (UNS N06625 and UNS N06852) and Nickel-Chromium-Molybdenum-Silicon Alloy (UNS N06219) Pipe and Tube
ASTM B444 / ASME SB444
Standard Specification for Nickel-Chromium-Molybdenum-Columbium Alloys (UNS N06625 and UNS N06852) and Nickel-Chromium-Molybdenum-Silicon Alloy (UNS N06219) Pipe and Tube
ASTM B622 / ASME SB622
Standard Specification for Seamless Nickel and Nickel-Cobalt Alloy Pipe and Tube
ASTM B668 / ASME SB668
Standard Specification for UNS N08028 and N08029 Seamless Pipe and Tube
ASTM B677 / ASME SB677
Standard Specification for UNS N08925, UNS N08354, and UNS N08926 Seamless Pipe and Tube
ASME SB690 / ASME SB690
Standard Specification for Iron-Nickel-Chromium-Molybdenum Alloys (UNS N08366 and UNS N08367) Seamless Pipe and Tube
ASTM B705 / ASME SB705
Standard Specification for Nickel-Alloy (UNS N06625, N06219 and N08825) Welded Pipe
ASTM B729 / ASME SB729
Standard Specification for seamless UNS N08020, UNS N08026, and UNS N08024 nickel alloy pipe and Tube
ASTM B829 / ASME SB829
Standard Specification for General Requirements for Nickel and Nickel Alloys Seamless Pipe and Tube
